Calcium silicate insulation board
Over the past years CASITHERM / SILCA has been the only German producer of calcium silicates to show that with innovative products you can continuously improve both the safety and productivity in the assembly of fireplaces. Our guarantee is the close contact to specialist craftsmen and the specialized trade and our treasure trove of experience obtained in the course of time, not least in the insulation in the industrial sector.
For many years furnace constructors inside and outside Europe have relied on the SILCA® 250KM calcium silicate insulation board authorized by the Deutsche Institut für Bautechnik Berlin (German Institute for Civil Engineering), national technical approval no. Z-43.14-117. The test results for the determination of the equivalent thicknesses according to the technical rules of the tiled stove and air heating building trade are shown in the following diagrams.
SILCA® 250KM is a real European champion. Thus the VKF Vereinigung Kantonaler Feuerversicherungen (Association of Swiss Cantonal Fire Insurance Underwriters) issued the Swiss Fire Prevention Approval no. 15202, the biggest Scandinavian research institute SINTEF issued certificate no. 120-0238, and for sure our SILCA® 250KM insulation board also achieves the results required by the new Austrian standard Ö-Norm B8311 in its issue 2013-12-15. Across the borders this means safety and untroubled pleasure in the building and heating of domestic fire places. According to standard EN 14 306:2010 SILCA® 250KM received the certificate no. 0432-CPD-420002242/2-6.
SILCA® 250KM replaces both fire protecting wall and thermal insulation in only one construction material and not only for this reason guarantees more favorable results than comparable products. The required thickness of the insulation layer is determined on the basis of the assembly instructions of the stove manufacturers, the technical rules TR-OL and further national regulations. Depending on the individual case of application and where appropriate, an active air ventilation has to be provided.
The main components of the SILCA calcium silicate boards are lime and sand. These are physiologically safe and Classified as environmentally compliant construction material. This is guaranteed by our modern production facilities, permanent quality control, external supervision and certification according to DIN EN ISO 9001: 2008. The environmental compatibility is certified by the environmental product declaration according to ISO 14025 and EN 15804 issued by the Institut Bauen und Umwelt e.V. (German institute for construction and environment), declaration nro. EPD-CSP-20180010-IBC1-DE.
Your advantages at a glance
- space saving due to thin insulation thickness
- environmentally compliant construction material
- physiologically safe
- fire protecting wall and thermal insulation in one single construction material
- large-size boards
- easy handling and assembling
- easy disposal as building waste
- applicable for insulation and construction
The boards are pressed on one of the world’s largest filter presses for the production of calcium silicates to a dimension of 3,000 x 1,250 mm. The standard dimensions are 1,250 x 1,000 mm, 1,250 x 500 mm and 1,000 x 625 mm. The standard thicknesses range from 30 mm to 100 mm. A further quality feature of the SILCA calcium silicate boards is the firm and dust-free moulding skin. Therefore, a further field of application is the lining of fireplaces.
Apart from the standard dimensions individual cuts can be produced directly in the plant on demand. SILCA® 250KM can be treated with standard wood machining tools and also be screwed on assembling. Further information on the assembly of our light construction flue shaft SILCA® PRO LC90.
|Material designation SILCA® 250KM|
|Approval in Germany||National technical approval no Z-43.14-117 valid for fireplace and tiled stove construction|
|Approval in Switzerland||Fire Prevention Approval no. 15202|
|Approval SINTEF NBL||120-0238 (50mm)|
|Fire resistance||EI 120 (80mm), DIN EN 13501-2|
|Reaction to fire||Non-combustible A1|
|Bulk density (± 10%)||250 kg/m³|
|Porosity||approx. 90 %|
|Compressive strength||> 1,4 MPa|
|Thermal resistance (board thickness 40 mm)||≥ 0,5 m² K/W|
|Thermal conductivity λ at 200 °C||< 0,1 W/m K|
|Thermal expansion at 500 °C||< 0,2 %|
|Standard dimensions in mm||3.000x1.250, 2.000x1.250, 1.250x1.000, 1.250x500, 1.000x625, 625x500|
|Standard thicknesses in mm||30-100|
